JSP/2012.04강의(MySQL)

7일차 Tiles

Bohemian life 2012. 5. 30. 14:15



header.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#header{width:100%; height:100px;
			background-color: green ;
   }
</style>

<div id="header">
	헤더
</div>


menu.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#menu {width:200px;
			background-color: orange ;
   }
</style>

<div id="menu">
	메뉴
</div>


footer.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#footer{width:100%; height:300px;
			background-color: teal ; ;
   }
</style>

<div id="footer">
	footer
</div>


body1.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#body  {
			background-color: gray;
   }
</style>

<div id="body">
	본문 1
</div>


layout.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>
<%@ taglib prefix="tiles" uri="http://tiles.apache.org/tags-tiles" %>
<!DOCTYPE html>
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
<title>Insert title here</title>
	<style>
		#tableLayout{  border:2px thin blue ;
					   border-style: solid;
					   border-width: 2px;
					   width:90%;
					   margin : 30px;
		}
		td {  border:2px thin blue ;
		      border-style: solid;
			  border-width: 1px;
		}
	</style>

</head>
<body>
	<table id="tableLayout">
		<tr>
			<td colspan="2">
				<tiles:insertAttribute name="header" />
				헤더가 들어갈 자리
			</td>
		</tr>
		<tr>
			<td width="25%" valign="top">
				<tiles:insertAttribute name="menu" />
				메뉴가 들어갈 자리
			</td>
			<td width="75%" valign="top">
				<tiles:insertAttribute name="body" />
				바디 본문이 들어갈 자리
			</td>
		</tr>
		<tr>
			<td colspan="2">
				<tiles:insertAttribute name="footer" />
				풋터가 들어갈 자리
			</td>
		</tr>
	</table>
</body>
</html>


web.xml
<?xml version="1.0" encoding="euc-kr"?>

<web-app xmlns="http://java.sun.com/xml/ns/javaee"
		xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
		xsi:schemaLocation="http://java.sun.com/xml/ns/javaee
		                    http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
		version="2.5">

	<!--  tiles 라이브러리를 사용하자 -->
	<servlet>
		<servlet-name>tiles</servlet-name>
		<servlet-class>org.apache.tiles.web.startup.TilesServlet</servlet-class>
		<init-param>
			<param-name>org.apache.tiles.impl.BasicTilesContainer.DEFINITIONS_CONFIG</param-name>
			<param-value>/WEB-INF/tiles-basic.xml</param-value>

		</init-param>
		<load-on-startup>1</load-on-startup>
	</servlet>

	<servlet>
		<servlet-name>TilesDispatchServlet</servlet-name>
		<servlet-class>
			org.apache.tiles.web.util.TilesDispatchServlet
		</servlet-class>
	</servlet>

	<!--  index.tiles 라고 요청하면  /WEB-INF/tiles-basic.xml에 선언된
	<definition name="index" template="/tiles/layout.jsp">
		를 호출합니다  -->
	<servlet-mapping>
		<servlet-name>TilesDispatchServlet</servlet-name>
		<url-pattern>*.tiles</url-pattern>
	</servlet-mapping>
</web-app>


tiles-basic.xml
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE tiles-definitions PUBLIC
       "-//Apache Software Foundation//DTD Tiles Configuration 2.1//EN"
       "http://tiles.apache.org/dtds/tiles-config_2_1.dtd">

<tiles-definitions>
	<definition name="index" template="/tiles/layout.jsp">
		<put-attribute name="header" value="/tiles/header.jsp"/>
		<put-attribute name="menu" value="/tiles/menu.jsp"/>
		<put-attribute name="body" value="/tiles/body1.jsp"/>
		<put-attribute name="footer" value="/tiles/footer.jsp"/>
	</definition>
</tiles-definitions>






header.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#header{width:100%; height:100px;
			background-color: green ;
   }
</style>

<div id="header">
	헤더
</div>


menu.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#menu {width:100%;
			background-color: orange ;
   }
</style>

<div id="menu">
	메뉴
</div>


footer.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#footer{width:100%; height:300px;
			background-color: olive ;
   }
</style>

<div id="footer">
	footer
</div>


body1.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#body  {
			background-color: gray;
   }
</style>

<div id="body">
	본문 1  <br />

	<a href="study2.tiles"  > 바디2로 이동하기</a>
</div>
body2.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#body  {
			background-color: gray;
   }
</style>

<div id="body">
	body2.jsp <br />
	<a href="study3.tiles"  > 바디3로 이동하기</a><br/>
	<img src="http://mijoo.pe.kr/zbxe/files/attach/images/101/545/002/1_2.jpg" />
</div>
body3.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#body  {
			background-color: gray;
   }
</style>

<div id="body">
	body3.jsp <br />
	<a href="study4.tiles"  > 바디4로 이동하기</a><br/>s
	<img src="http://contents.dt.co.kr/images/200901/2009012902011931716001.jpg" />
</div>
body4.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>

<style>
#body  {
			background-color: gray;
   }
</style>

<div id="body">
	body4.jsp <br />
	<a href="study1.tiles"  > 바디1로 이동하기</a><br/>
	<img src="http://www.fallight.com/attach/1/1499946474.jpg" />
</div>


layout.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>
<%@ taglib prefix="tiles" uri="http://tiles.apache.org/tags-tiles" %>
<!DOCTYPE html>
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
<title>
	<tiles:getAsString name="title"/>
</title>
	<style>
		#tableLayout{  border:2px thin blue ;
					   border-style: solid;
					   border-width: 2px;
					   width:90%;
					   margin : 30px;
		}
		td {  border:2px thin blue ;
		      border-style: solid;
			  border-width: 1px;
		}
	</style>

</head>
<body>
	<table id="tableLayout">
		<tr>
			<td colspan="2">
				<tiles:insertAttribute name="header" />
				헤더가 들어갈 자리
			</td>
		</tr>
		<tr>
			<td width="20%" valign="top">
				<tiles:insertAttribute name="menu" />
				메뉴가 들어갈 자리
			</td>
			<td width="80%" valign="top">
				<tiles:insertAttribute name="body" />
				바디 본문이 들어갈 자리
			</td>
		</tr>
		<tr>
			<td colspan="2">
				<tiles:insertAttribute name="footer" />
				풋터가 들어갈 자리
			</td>
		</tr>
	</table>
</body>
</html>


web.xml
<?xml version="1.0" encoding="euc-kr"?>

<web-app xmlns="http://java.sun.com/xml/ns/javaee"
		xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
		xsi:schemaLocation="http://java.sun.com/xml/ns/javaee
		                    http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
		version="2.5">

	<!--  tiles 라이브러리를 사용하자 -->
	<servlet>
		<servlet-name>tiles</servlet-name>
		<servlet-class>org.apache.tiles.web.startup.TilesServlet</servlet-class>
		<init-param>
			<param-name>org.apache.tiles.impl.BasicTilesContainer.DEFINITIONS_CONFIG</param-name>
			<param-value>/WEB-INF/tiles-basic.xml</param-value>

		</init-param>
		<load-on-startup>1</load-on-startup>
	</servlet>

	<servlet>
		<servlet-name>TilesDispatchServlet</servlet-name>
		<servlet-class>
			org.apache.tiles.web.util.TilesDispatchServlet
		</servlet-class>
	</servlet>

	<!--  index.tiles 라고 요청하면  /WEB-INF/tiles-basic.xml에 선언된
	<definition name="index" template="/tiles/layout.jsp">
		를 호출합니다  -->
	<servlet-mapping>
		<servlet-name>TilesDispatchServlet</servlet-name>
		<url-pattern>*.tiles</url-pattern>
	</servlet-mapping>
</web-app>



tiles-basic.xml
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE tiles-definitions PUBLIC
       "-//Apache Software Foundation//DTD Tiles Configuration 2.1//EN"
       "http://tiles.apache.org/dtds/tiles-config_2_1.dtd">

<tiles-definitions>
	<definition name="index" template="/tiles/layout.jsp">
	    <put-attribute name="title" value="title를 사용하자"/>
		<put-attribute name="header" value="/tiles/header.jsp" />
		<put-attribute name="menu"  value="/tiles/menu.jsp"/>
		<put-attribute name="body" value="/tiles/body1.jsp"/>
		<put-attribute name="footer" value="/tiles/footer.jsp"/>
	</definition>
	<!--  wild Card Tiles 2.1버전부터는 설정파일에서
	*와일드카드를 사용하여 설정파일의 내용을 줄이는 방법이 지원된다. -->
	<definition name="study*" extends="index">
		<put-attribute name="body" value="/tiles/body{1}.jsp"/>
	</definition>

	<!-- *study* = >  /~/{1}study{2}.jsp
		예: androidStudy01.tiles => /study/androidStudy01.jsp
		예: htmlStudy03.tiles => /study/htmlStudy03.jsp
		-->
	<!--    day02_01.jsp  ,  day02_01.tiles -->
</tiles-definitions>


09.Tiles.zip
